Der HCH2 Rollenschneider mit Aufwickelfunktion nutz mechanisches Spannfutter ohne Spannzangen und eine Führungseinheit zum Abwickeln, zeitsparend und zuverlässig. Friktionsaufwicklung für geschmeidige Prozesse. Der Rollenschneider mit Aufwickelfunktion eignen sich zum Schneiden und Aufwickeln von Etikettenrollen mit einer Breiten von 1300mm bis 1700mm und erreicht eine Arbeitsgeschwindigkeit von bis zu 400m/min. So sind eine hohe Arbeitsgeschwindigkeit und Zuverlässigkeit garantiert.
Papier, selbstklebendes Papier/ Folien, Schutzfilme
Modell | HCH2-1300A | HCH2-1700A |
Abwickelbreite | 1300mm | 1700mm |
Arbeitsgeschwindigkeit | 400m/min | 400m/min |
Schnittgenauigkeit | ±0.03mm | ±0.03 mm |
Abwickeldurchmesser | φ1100mm | φ1100mm |
Aufwickeldurchmesser | 2*φ600mm | 2*φ600mm |
Servomotorantrieb | 4 kw | 4kw |
Servomotor Leistung | 11kw | 11kw |
Maschinengröße | 2700*2650*1580mm | 2800 *3150* 1600mm |
Maschinengewicht | 3500kg | 4000kg |
